> Thermo-manometer > Plastic case type
-
Item Name：Plastic case type
Model Number：LED-PT-03
Material：
Size：
Package Info：
Payment Terms：
Shipping Method：
Minimum Order Quantity：
Certificate：
Plastic case with check valve
Model: LED-PT-03
Application:
Boiler and heating industry
Description:
Nominal size (mm):Ø80
Panel hole (mm):
Scale ranges: 0-4,6bar
0-1200C, 0-160 0C
Accuracy class: 2.5
Design:Bimetal thermometer system, bourdon tube pressure system
Wetted parts: Copper alloy
Connection: Lower or center back direct mount
Case material: Plastic
Window: Plastic
Options/notes:
Red indication pointer
Model: LED-PT-03
Application:
Boiler and heating industry
Description:
Nominal size (mm):Ø80
Panel hole (mm):
Scale ranges: 0-4,6bar
0-1200C, 0-160 0C
Accuracy class: 2.5
Design:Bimetal thermometer system, bourdon tube pressure system
Wetted parts: Copper alloy
Connection: Lower or center back direct mount
Case material: Plastic
Window: Plastic
Options/notes:
Red indication pointer
